รีวิว Power supply ปรับค่าได้ 0-30VDC

Display 3 Digits LED 0-30V Mini DC Power Supply


KPS series is a single set of output, high precision double display switch dc power

supply.Machines have complete operating protection function, with high performance,

low ripple, high stability , light weight and small volume etc. Current limiting protection

can make KPS power supply and load against accidental damage.

KPS series power supply with low temperature control circuit, a cooling fan noise is low.

Special point

1, have complete operating protection function

2, highly efficient, low ripple, small volume, light weight

3, double display voltage, current, and high precision

4, voltage stabilization, current limiting, simple operation

5, dual voltage input and convenient choice

6, temperature control fan heat dissipation, low noise

7, Double potentiometer more precise adjustment

Technical indicators

Input voltage:AC 110V/220V/50/60Hz

Output voltage:0 - 30V

Output current:0 - 10A

Voltage resolution:100mV

Current resolution:10mA

Power effect:CV≤1%+10mV

Effect of load:CV≤1%+10mV

Ripple and noise:Vp-p≤1%

Voltage display precision:±1%+1digits

Current display precision:±1%+2digits

Net/gross Weight (KG):1.9

Volume (mm):81WX165HX220L

Operating environment:(-10-45) Rh<90%

Working time:a long time

Standard Accessories:Power cordX1 output lineX1

instruction bookX1 Warranty card certificationX1

นใจติดต่อ Line ID:backhold1
